AC Adapter 13V-19V

AC Adapter Model: PA-1131-08
Acer P/N: AP.13503.001, AP.13503.006

INPUT: 100-240V~ 1.5A, 50-60Hz
OUTPUT: 19V 7.1A 135W
Connecter size: Int. Diameter: 2.50mm
                       Ext. Diameter: 5.50mm

Dimensions: 165 x 68 x 40 mm

*When buying any compatible AC adapter, please take note the type of power cord(2 or 3-prong) used.

**Please take note, 3 wire AC power cord not included.

AC Adapter Model: PA-1161-01
P/N: 76-011161-4C

INPUT: 100-240V~ 2.25A, 50-60Hz
OUTPUT: 20V 8.0A 160W
Connector: 4-pin DIN

Dimensions: 180 x 67 x 42 mm

*For use with Laptop under 258SA, 258KA, 766, L373N1 notebook series:
- Alienware Area-51m 766
- Clevo 5620D
- PortaNote 5600D
- ViewBook VB1500S

*Please do not mix up with another adapter with the same model number but different connector size, please check carefully the connector's measurement of your adapter.

**Please take note, 2 wire AC power cord not included.

AC Adapter Model: PA-1161-02
P/N: 76-010160-5A

INPUT: 100-240V~ 2.25A, 50-60Hz
OUTPUT: 20V 8.0A 160W
Connecter size: Int. Diameter:  2.50mm
                       Ext. Diameter:  5.50mm
                       Length          : 12.00mm

Dimensions: 180 x 67 x 42 mm

*Please check carefully and do not mix up with another adapter with the same model but different Voltage, Ampere and Connector size(Tip).

**Please take note, 3 wire AC power cord not included.
