Categories
By LITEON
AC Adapter Model: PA-1900-08R1
Series PPP012L-S
HP Part No.: 393954-001
AC Adapter Model: PA-1900-18H1
Series: PPP014L-S
HP Part No.: 374473-001
By HIPRO
AC Adapter Model: HP-AP091F13P LF
Series PPP012H-S
HP Part No.: 393954-002
AC Adapter Model: HP-AP091F13P
Series PPP012H-S
HP Part No.: 374473-002
By DELTA
AC Adapter Model: ADP-90GH B
Series PPP012D-S
HP Part No.: 393954-004
Replace with HP Spare: 397224-001, 374791
Compatible HP Spare: 393954-001, 403900-001, 408488-001, 409515-001, 412267, 432309-001
* PLEASE NOTE : 408488-001 has been replaced by 432309-001 *
INPUT: 100-240V~ 1.5A, 50-60Hz
OUTPUT: 19V 4.74A 90W Max.
Connecter size: Int. Diameter: 1.70mm
Ext. Diameter: 4.80mm
Dimension: 125 x 49 x 30 mm
*For use with Compaq and HP notebook products only.
*Please take note, 3 wire AC power cord not included.
INPUT: 100-240V~ 2.25A, 50-60Hz
OUTPUT: 19V 9.5A 180W
Connecter size: Int. Diameter: 2.50mm
Ext. Diameter: 5.50mm
Dimensions: 170 x 85 x 40 mm
*Please take note, 3 wire (IEC C13) AC power cord not included.
90W combination adapter - 100-240VAC input, 10-32VDC input
HP P/N: 355867-001
Replace with HP Spare: 366068-001
Series: HSTNN-AA04
P/N: DV574A/PC628A
AC INPUT: 100-240V~ 1.6A, 50-60Hz
DC INPUT: 10-32V 11A
Charge Mode Output: 18.5V 4.9A
Non-Charge Mode Output: 15.0V 6.0A
Total 90W Max.
Connecter size: Int. Diameter: 1.70mm
Ext. Diameter: 4.75mm
Dimension: 160 x 64 x 30 mm
Please take note, Automobile/truck/aircraft Dongle and 3 wire AC power cord not included.
HP SPS: 496813-001
AC Adapter Model: HP-A0301R3
Series PPP018H
HP Part No.: 493092-002
HP SPS: 535630-001
AC Adapter Model: PA-1300-04HV
Series PPP018L
HP Part No.: 534554-002
INPUT: 100-240V~ 1A, 50-60Hz
OUTPUT: 19V 1.58A, 30W
Connecter size: Int. Diameter: 1.70mm
Ext. Diameter: 4.00mm
Length : 11.00mm
*Please take note, 3 wire AC power cord not included.
Model: VAN40B-12B
INPUT: 100-240V~ 1.0A, 50-60Hz
OUTPUT: 12V 3.0A 36W
Connecter size: Int. Diameter: 2.50mm
Ext. Diameter: 5.50mm
Dimension: 92 x 49 x 31 mm
*Please take note, 2 wire AC power cord not included.
*When buying any compatible AC adapter, please take note the type of power cord(2 or 3-prong) used.
**Please take note, 3 wire power cord not included.
*Compatible FRU P/N:
*2-pin/prong model:
By Sanken - FRU P/N: 85G6705, P/N: 85G6704
*3-pin/prong model:
By Sanken - FRU P/N: 12J1448, P/N: 12J1447
By Sanken - FRU P/N: 02K7015, P/N: 02K7014
By Sanken - FRU P/N: 85G6735, P/N: 85G6733
INPUT: 100-240V~ 1.0A-0.55A, 50-60Hz
OUTPUT: 16V 2.2A 35W
4-pin Connector
Dimensions: 98 x 60 x 25 mm
*When buying any compatible AC adapter, please take note the type of power cord(2 or 3-prong) used.
**Please take note, 3 wire power cord not included.
*This IBM Thinkpad 72W Ultraportable Slim AC adapter has a few set of FRU Part Number due to different manufacturer. There are all similar and have the same specification.
*Compatible FRU P/N:
*2-pin/prong non-PFC model:
By Astec - FRU: 08K8205, P/N: 08K8204
By Astec - FRU: 92P1017,
By Delta - FRU: 08K8209, P/N: 08K8208
By Delta - FRU: 92P1021, P/N: 92P1020
By Sanken - FRU: 08K8213, P/N: 08K8212
By Sanken - FRU: 92P1025,
*3-pin/prong PFC model:
By Astec - FRU: 08K8203, P/N: 08K8202
By Astec - FRU: 92P1015,
By Astec - FRU: 93P5017, P/N: 08K8202
By Delta - FRU: 08K8207, P/N: 08K8206
By Delta - FRU: 92P1019,
By Sanken - FRU: 08K8211, P/N: 08K8210
By Sanken - FRU: 92P1023,
INPUT: 100-240V~ 1.5A-0.9A, 50/60Hz
OUTPUT: 16V 4.5A 72W
Connecter size: Int. Diameter: 2.50mm
Ext. Diameter: 5.50mm
Length : 10.00mm
Dimensions: 114 x 50 x 28 mm
*For use with the following notebook:
*When buying any compatible AC adapter, please take note the type of power cord(2 or 3-prong) used.
**Please take note, 3 wire AC power cord not included.
IBM AC Adapter 90W 20V
*Compatible FRU P/N:
*3-pin/prong model:
By Astec - FRU: 92P1104, P/N: 92P1103
By Liteon - FRU: 92P1108, 42T4429 , P/N: 92P1107
By Sanken - FRU: 92P1112, P/N: 92P1101
By Delta - FRU: 42T5275, P/N: 42T5274
*2-pin/prong model:
By Astec - FRU: 92P1106, 42T5000, P/N: 92P1105
By Liteon - FRU: 92P1110, 93P5026, P/N: 92P1109
By Sanken - FRU: 92P1114, P/N: 92P1113
By Delta - FRU: 42T5277, P/N: 42T5276
INPUT: 100-240V~ 2.4A, 50-60Hz
OUTPUT: 20V 4.5A 90W
Connector Size: Int. Diameter: 5.60mm
Ext. Diameter: 7.90mm
(Signal pin in the middle)
Dimensions: 125 x 50 x 30 mm
*When buying any compatible AC adapter, please take note the type of power cord(2 or 3-prong) used.
**Please take note, 3 wire AC power cord not included.
